- Selectable 2 or 3 Way Input:
- Front and Rear
- Front, Rear and Subwoofer
- 3-Way Output:
- Front, Rear and Subwoofer
- Sub Out Low Pass Control :
- Frequency Control: 32-250Hz
- Bass EQ: 0-12db Boost @ 25-250Hz
- Phase Shift: 0-180 Degrees
- Audio Mode: Mono or Stereo
- Output Level Control
- Rear High Pass Control:
- Frequency Control: 40-400Hz
- Crossover Slope: 6dB or 18dB
- Output Level Control
- Front High Pass Control: 40-400Hz
- 20x Multiplier: 800-8,000Hz
- Crossover Slope: 6dB or 18dB
- Output Level Control
- Frequency Response: 20-40,000Hz
- Maximum Output: 7 Volts
- S/N Ratio: >90dB
- Dimensions: 5" x 1.75" x 7"
