Music has changed. Today we can stream it, download it, play whatever we like, whenever we like. But all too often, this convenience has come with a price: sound quality. That is, until now. Our new RA-12 has all the connectivity you need to make the most of your digital music. And the advanced audiophile technology to really bring it to life. The RA-12 – uncompromising sound, for a connected world.
DIMENSIONS (W × H × D)
430 × 92 × 342mm
17" × 3.6" × 13.5"
FRONT PANEL HEIGHT
80mm (3.06")
POWER REQUIREMENTS
230V, 50Hz
POWER CONSUMPTION
300W
STANDBY POWER CONSUMPTION
<0.5W
WEIGHT
8.02kg (18lbs.)
BTU RATING (4Ω, 1/8th power)
517 BTU/h
CONTINUOUS POWER OUTPUT
60W/Ch (All channels driven, 8Ω)
TOTAL HARMONIC DISTORTION (THD)
(20Hz–20kHz) <0.03%
FREQUENCY RESPONSE
Line Level Inputs: 10Hz - 100kHz ±1dB
Digital Inputs: 10Hz - 95kHz ±3dB
Phono Input: 20Hz - 15kHz ±0.3dB
S/N RATIO (IHF "A" Weighted)
Line Level Inputs: 100dB
Digital Inputs: 100dB
Phono Input: 80dB
