MATCH er nye spesialtilpassede produkter fra tyske Audiotec Fischer (Brax, Helix)
- Simple Plug & Play connection to original sound systems using vehicle-specific adapter cables
- Up to 16 different DSP setups preprogrammed and available at the push of a button
- Display the selected setup via the 7-segment display
- Low level sub out for a separate PP 1Sub subwoofer amplifier
- 56-bit DSP technology and 24-bit AD/DA converter
- Start/stop capable down to 6 volts supply voltage
- MCM power supply technology with „ECO mode"
- Plug jack for optional cable remote control
- State-of-the-art SMD technology for a more compact design and maximum reliability
- Four-layer printed circuit boards for best possible power and signal transmission
- Output Power RMS / Max
- at 4 Ohms 4 x 35 Watts / 70 Watts
- at 2 Ohms 4 x 50 Watts / 100 Watts
- Frequency response 20 Hz - 22.000 Hz
- Number of inputs 4 x Highlevel
- DSP resolution 56 Bit
- DSP processing power 50 Mhz
- Total harmonic distortion (THD) < 0,03 %
- Signal-to-noise ratio > 100 dB
- Damping factor > 100
- Input impedance 30 Ohms
- Dimensions (H x W x D)185 x 44 x 124 mm
Passer følgende BMW:
- Setup Car model Type Subwoofer optimization
- 1 1er Fünftürer / 5-doors E87 PP 7E-D
- 2 1er Cabrio / Convertible E88 PP 7E-D
- 3 3er Limousine / Sedan E90 PP 7E-D
- 4 3er Limousine / Sedan E90 PP 10E-D
- 5 3er Touring E91 PP 7E-D
- 6 3er Coupe E92 PP 7E-D
- 7 3er Coupe E92 PP 10E-D
- 8 5er Limousine / Sedan E60 PP 7E-D
- 9 5er Limousine / Sedan E60 PP 10E-D
- 10 5er Limousine / Sedan F10 PP 7E-D
- 11 5er Limousine / Sedan F10 PP 10E-D
- 12 5er Touring E61 PP 7E-D
- 13 X1 E84 PP 7E-D
- 14 X3 F25 PP 7E-D
- 15 X3 F25 PP 10E-D
- 16 Z4 E89 PP 8E-D
